- The MSD RPM Activated Switch enables accurate, engine-speed-based control of performance components for automatic operation.
- Offered as a standard RPM Activation model (PN 8950) or as an RPM Window Switch version (PN 8956)
- The standard model triggers a connected circuit at a chosen RPM and keeps it engaged until engine speed falls below the set point
- The window switch model allows independent on and off RPM settings within a specified operating range
- Designed for use with factory inductive ignition systems or MSD Ignitions on 4-, 6-, and 8-cylinder engines
- Rated to handle up to 1.5 amps; RPM modules are sold separately
- Covered by a 1-Year Limited Warranty
Maximizing performance often comes down to precise control. From launching off the starting line to managing nitrous systems or activating auxiliary components, having equipment respond at the exact engine speed you choose can significantly impact results. The MSD RPM Activated Switch is designed to provide consistent, automatic RPM-based control for a variety of performance applications.
This switch is offered in two versions to suit different needs. The RPM Activated Switch (PN 8950) includes two output leads—one designed to ground a circuit and another to interrupt a circuit. After installing the appropriate RPM module and integrating the switch into the selected circuit, activation occurs when the engine reaches the chosen RPM and remains active until engine speed drops below that setting. The RPM Window Switch (PN 8956) allows users to define both an activation RPM and a shutoff RPM within a specified range, making it particularly useful for applications such as disabling nitrous before reaching the rev limiter. Both models are compatible with factory inductive ignition systems as well as MSD Ignition controls, support 4-, 6-, and 8-cylinder engines, and are rated to handle up to 1.5 amps. RPM modules are sold separately.
Providing dependable RPM-triggered operation and flexible setup options, this switch enhances accuracy and safeguards critical performance components. Backed by a 1-Year Limited Warranty.
